M5Stack® AC Socket Connector RS485 AC Outlet 10A Support Mutiple Device Series Connection STM32F030F4

Description: This is an upgrade of a normal AC socket outlet, which empowers the user to customize the AC outlet through RS485 series. Serial communication control can include multiple AC sockets, have them serial connected in the same RS485 main bus, can be applied to a typical industrial application scenario. Let's break it down a little bit, start with the bottom part. The whole AC socket is consist of two parts. For people who are familiar with M5 industrial product series, would recognize the base at the bottom is BASE26. we put a 3pin inlet socket at one customizable side of BASE26. This is where we power the AC socket from. The top is where goes in the AC plug, and the relay control inside would switch on and off the power in here. To get more AC socket connected in series, we would use an HT3.96 terminal connectors, as you can see the orange socket in the picture. The bottom part is mainly in charge of converting the AC power 220V to DC 5V to power the microprocessor STM32F030F4 and RS485 related circult. As you can see from the picture, two parts wire connected by M-Bus socket and a pair of power wire. A red led indication is placed on top. Product Features: RS485 OUTLET Serial communication protocol: ModBUS-RTU support Mutiple device Series connection STM32F030F4 Embedded 4x M3 Nut Build with BASE26 INPUT : 100-240V OUTPUT: 10A Power Status indicator Weight and Size: Product size:54mm x 54mm x 61mm Product weight:130g Package Included: 1x AC Socket Application Smart AC Socket Outlet With wire control of RS485 ACSocket Modbus RTU Protocol Description: Communication uses RS485, 1 bit start bit + 8 bit data bit + 1 bit end bit Baud rate 9600 3.Device ID defaults to AAH Address 00H is the broadcast address, the slave does not reply Instruction: (hexadecimal) (Modbus RTU format) 1. Write coil The host sends: AA 05 00 00 FF 00 95 E1 (closed coil) AA 05 00 00 00 00 D4 11 (disconnect coil) Send content bytes Send a message Remarks module address 1 AAH 00H is the broadcast address Function code 1 05H Write a single coil start register address 2 0000H Coil 0 Address Write data 2 FF00H FF00H: indicates coil closure | 0000H: indicates coil disconnection CRC check 2 XXXXH CRC code of all previous data (CRC16) Slave response: The operation successfully returns the original data: AA 05 00 00 FF 00 95 E1 Operation failed to return: AA 85 error code CRC_L CRC_H 2. Reading the coil The host sends: AA 01 00 00 00 01 E4 11 Send content bytes Send a message Remarks module address 1 AAH 00H is the broadcast address Function code 1 01H read coil start register address 2 0000H Coil 0 Address Read quantity 2 0001H can only be 0001H CRC check 2 XXXXH CRC code of all previous data (CRC16) Slave response: The operation returns successfully: Address Function code Return data length Coil Status CRC_L CRC_H AA 01 01 01 B0 6C Coil status: 01H -> coil closed 00H -> coil disconnected Operation failed to return: AA 81 error code CRC_L CRC_H 3. Write device address The host sends: AA 41 00 00 00 12 A4 13 Send content bytes Send a message Remarks module address 1 AAH 00H is the broadcast address Function code 1 41H Set module address start register address 2 0000H Address module new address 1 12H 1 byte CRC check 2 XXXXH CRC code of all previous data (CRC16) Slave response: The operation successfully returns the original data: AA 41 00 00 00 12 A4 13 Operation failed to return: AA C1 error code CRC_L CRC_H 4. Broadcast recovery device address The host sends: 00 42 00 00 A0 30 Send content bytes Send a message Remarks broadcast address 1 00H 00H is the broadcast address Function code 1 42H Recovery address is AAH start register address 2 0000H Address CRC check 2 XXXXH CRC code of all previous data (CRC16) Slave response: none
