Scale DIY Kit Including Weight Sensor High Precision Electronic Scale Weighing Machine M5Stack® for Arduino - products t

M5StickC Click here to buy More M5Stack Item Click here to openDescription M5SCALE DIY Kit is a DIY kit of M5 that implements a digital scale which makes it more of an Application approach development kit The overall structure is made of acrylic material The electronic part is the main controller M5StickC and a WEIGH unit A cantilever beam sensor is used to detecting the bend over forced on top of the scale by object weight it will transfer the deformation into a voltage signal and as an input of WEIGH sensor which will be captured and read by M5stickC Other than that there also some small components that is included in the kit you have the total freedom to assembly the whole thing and reprogram it as you like The software is open sourced on GitHub you can program it either with UIflow or for The le go holes on bottom board allow you to place more M5 sensors for extension functions Plus M5StickC is wifi available you have the freedom to build something impressive Product Feature Dimension Finish Assembly 100mm 100mm 43mmCantilever beam sensor 80mm 12 7mm 12 7mmDIY Digital ScaleM5StickC WeightMeasurement Range 10KG in default code Open source codeLe go HolesAcrylic materialLoad cell technical parameters Range 20kgOutput sensitivity 1 00 1mV VLead wire power line red signal positive white signal negative green ground wire black Package Included 1x M5SCALE DIY Kit1x User ManualApplication High precision electronic scaleSmall range weighing
