xcluma AD9850 DDS 0-40MHz Signal Generator Module 2 Sine Wave And 2 Square Wave Output(Blue)

2 sine wave and 2 square wave outputAD9850 Frequency: 0-40MHzAfter the 20-30MHz frequency harmonics increases, the waveform will become unclean.Square Wave: 0-1MHzLow-pass filter with 70MHz, so the waveform better than SNParallel and serial data input can be selected via a jumperDA produced the benchmark pin (PIN12) leads for easy adjustment to do the magnitude of the output waveform ApplicationComparator reference input voltage generated by the variable resistor, the resistor can be adjusted duty cycle square wave of differentActive AD9850 125MHz crystal oscillator modules
