bluetooth Control Version C400 4WD Smart Chassis Car DIY Remote Control Kit for Arduino with bluetooth Module+UNO R3 Board+Motor Driver Board

Introductions: The C400 Car Kit is bluetooth control version. It will come with 4Pcs TT motor 2/4 motor drive board,UNO development board and bluetooth module. Meet your requirements for Arduino DIY cars C400 Car Kit parameters: - Size: 22.2*19*6cm (length * width * height - Net weight: 0.57kg - Material: aluminum alloy - Wheel: 60mm plastic wheel - Motor: TT motor - Control method: bluetooth version TT Motor parameters: - Voltage 6V (recommended at 3-6V best) - Strong magnetic, anti-interference Voltage no-load current no-load speed 6V 250mA 24010% rpm 3V 170mA 11010% rpm About 4 Road& 16 Road Servo control Board: If you want to know more, please click here Features: - 16-way servo and four-way motor drive board, using TB6612 four-way drive, PCA9685 for 16-way servo control. - Bring out the Arduino UNO I/O pin; - The maximum input voltage of the power supply is 15V/DC; - Reserve bluetooth & WIFI module sockets; - Reserve PS2 handle socket; - Four-way DC motor drive, single-channel maximum drive current 1.2A average / 3.2A peak; - 16-way servo drive pin, power supply can be switched by external/internal power supply of jumper cap; Product technical specifications: 1. Power input: Motor power supply (VM): 4.5V ~ 36V, can be powered separately; Servo power supply (VIN): 5 ~ 18V, can be powered separately; 2 Single power supply use: Open circuit VM and VIN, (separately control the motor, 6 ~ 36V); Open circuit VS and VIN, separately control the servo (6 ~ 18V); Short-circuit VM and VIN while shorting VS and 5V. Simultaneous control of motor (6 ~ 18V) and 16 5V servo. Package Included: 1 set Bracket 4 x Motor 4 x Wheels with Screw 1 x 2/4 motor drive board(blue and green color random) 1 x UNO development board 1 x bluetooth module
