ZVS DC-DC 45V To 390V 5A Adjustable Regulator Voltage Booster Module Capacitor Charging

Parameter:Size: 60*50*22mm (length*width*height)Input voltage: two input voltage ranges are selectable (by jumper selection on the back of the PCB, shipping defaults to 10-32V input)1.8-16V input (for Three-String Li-Ion and 12V battery applications)2.10-32V input (for wide input voltage range applications)Input current: 5A (max)Static operating current: 15mA (12V or 50V, the higher the output voltage, the higher the static current will increase)Output voltage: 45-390V continuously adjustable / 45-390V continuously adjustable (this module has a voltage regulator function, the output voltage is not stable after adjusting, does not change with the input voltage change)Output current: 0.2A MAX (related to the input and output voltage difference, the higher the output voltage, the smaller the output current)Output power: 40W (peak 70W)Operating temperature: -40 ~ +85 degrees (enhance the heat when the ambient temperature is too high)Operating frequency: 75KHz Conversion efficiency: up to 88% (efficiency related to input, output voltage, current, differential pressure) Short-circuit protection: yes. (Input 10A fuse, please do not directly short-circuit the output arc! The direct short-circuit arc may damage the rectifier device, if you want to short-circuit the arc, please connect the power resistor in series)Overcurrent protection: yes. (The input current exceeds 4.5A, reducing the output voltage)Overvoltage protection: yes. (output voltage exceeds 410V, lower output voltage)Reve
