YAHBOOM® 3-Channel PID Infrared Tracking Sensor Module + XH2.54 5Pin 15CM Cable for Smart Robot

YAHBOOM® 3-Channel PID Infrared Tracking Sensor Module + XH2.54 5Pin 15CM Cable for Smart Robot
sku: 1830813
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$25.99
Shipping from: China
   Description
Description This is a tracking module an output analog value 0 1023 It can adapt to many complex environments users can adjust the parameters in the program according to the actual situation to modify trigger threshold which detecting changes in the angle of the curve track On board 3 channel infrared tracking probe can simultaneously detect the middle track line and detect the left and right edges We can install it on the smart car with screws and copper or rivets to complete the high precision tracking Feature 3 channel analog value output It can adapt to multiple complex environments and achieve high precision line inspection by adjusting parameters in code It support XH2 54 5Pin cable and DuPont line connection It can be fixed on the smart car by rivets or screws and coppers Specification Name 3 way tracking moduleVoltage range DC 3 3V to 5VWorking current 30mA 3 3V 60mA 5VDetection distance 10mm 50mmOutput signal analog output 0 1023 Installation aperture M3 copper column screwScope of application suitable for black line tracking of small carsCompatibility Compatible with arduino micro bit Raspberry Pi 51 STM32Interface 5Pin XH2 54 interfaceSize 40mm 29mmPackage Includes 3 channel infrared tracking sensor module 1OR3 channel infrared tracking sensor module 1XH2 54 5Pin 15CM Cable 1TutorialYahboom 3 channel tracking module
