XY-T01 Digital Thermostat Heating Refrigeration Temperature Control Switch Temperature Controller Module

Product Function: Set Temperature ---- SetT; Backlash Temperature-----BackT; 1. Heating Mode 'H': When Temperature ≤ SetT - BackT ;Relay conduction, heating equipment begin to work; When Temperature ≥ SetT, Relay disconnect, heating equipment stop work; 2. Refrigeration mode 'C': When Temperature ≥ SetT + BackT ;Relay conduction, refrigeration equipment begin to work; When Temperature ≤ SetT ;Relay conduction, refrigeration equipment stop work; 3. High Temperature Alarm 'ALA': When Temperature ≥ Alarm Temperature, The system opens the sound and light alarm, and disconnects the relay, any key stops the sound light; 4. Delay Start ‘OPH': When a normal heating or refrigeration work is done, the system starts to time T, and only after the T≥OPH, the system can carry out the next round of heating or refrigeration work; 5. Temperature Correction Function OFE(-10.0 ~ 10.0°): The system will work for a long time and may have deviations that can be corrected by this function, Temperature = Measured + Calibration; 6. Parameter Remote Read/Set: The parameters such as setting temperature, backlash temperature and temperature correction can be set through UART. 7. Real-time Temperature Report: If the temperature reporting function is turned on, the product is transmitted to the terminal by the UART at 1s intervals, which facilitates data collection; 8. Relay enable (default enable): If the relay is disable, the relay remains disconnected; 9. Restore factory Settings: At the same time press the STOP, set key more than 3S, restore factory settings; Working mode setting /backlash temperature : 1. In the running interface, short press SET key, enter the Quick setting interface; 2. After entering the Quick Setup interface, switch the parameters 3. Through the UP DOWN key, modify the parameter value, support short press/long press; 4. Long press SET to build more than 3S or continuous 6S without any key operation, exit quickly set the interface, and save parameters; Alarm temperature/delay Start /temperature correction: 1. In the operating interface, long press SET more than 3s, enter the parameters to set the interface; 2. Enter the parameter to set the interface, through the short press SET key to switch to set the parameters ; 3. through the UP DOWN key, modify the parameter value, support short press/long press; 4. Long press SET 3s above or continuous 6S without any key operation, exit parameter set interface, and save parameters; How to turn on high temperature alarm (default off): Enter the parameter setting interface, switch to the alarm parameter ALA , turn on or off the high temperature alarm function by short pressing the STOP button, and if the high temperature alarm function closes, ALA displays '----' as a reminder; How to turn on delay start (default 0ff): Enter parameter setting interface, switch to alarm parameter OPH, turn on or off high temperature alarm function by short Press STOP button, if high temperature alarm function closes, OPH show '----' to remind; Note: Meaturing temperature range: -50? to 110? Package Included: 1 x XY-T01 Digital Thermostat
