XH-W1419 AC 220V Tin Furnace Heating Platform PID Thermostat Automatic Thermostat Controller Development Design

Specification Product Name PID Thermostat ControllerProduct model XH W1419Temperature measurement range 100 1000 ℃Temperature measurement accuracy ± 0 1 ℃Temperature control range 0 500 ℃Temperature control accuracy 0 1 ℃Temperature probe 1 m K type thermocouple M6 thread probePower supply voltage AC220VApplicable environment 15 55 ℃ 20 85 RHOutput type SCR direct outputDimension 110 68 39mmProduct weight 174gPackage included 1 x PID Thermostat ControllerHow to set the temperature value Short press the LEFT key to set the temperature value to flicker short press again to switch the number of digits press ADD and DEC to adjust the value 5 seconds without operation automatically save and exit How to set the high temperature alarm Long press the SET key for 5 seconds to enter the internal menu short press the SET key again to switch to P4 press the LEFT key and the high temperature alarm value starts to flash press the LEFT key again to switch the number of digits and press ADD and DEC to adjust the value PID control Ordinary thermostats heat up when power is turned on and power off when the set value is reached but the temperature will rise a few degrees or even higher after power off This is caused by temperature inertia which is a normal phenomenon while PID thermostats can To solve this problem it switches quickly when it is working and when the temperature is approaching the set value it achieves the purpose of constant temperat
