XH-W1411 12V 10A Smart Electronics LED Digital Thermometer Temperature Controller Switch Module

Specifications Temperature range 55 120℃Temperature measurement accuracy 0 3℃Resolution 0 1℃Temperature range 19 99℃Control accuracy 1℃Temperature probe NTC10K B3950 comes standard with 1 meter waterproof probeSupply voltage 12VTemperature 25 55℃ Humidity 20 85 non condensing Output Type 10A relay outputsSize 90 60mm 3 54 2 36Hole size 70 50mm 2 76 1 96Features The board and plastic panels fixed column compartment and lock nut Connect the power supply according to the drawings and load control line By drawing on the chassis opening 70 50mm then tighten the screws after the thermostat embedded Paste Mask After power if the temperature in the interval starts immediately output to stop off value Start temperature For example want to control the production of hot water heated to 60 degrees stop stop again begin heating to 45 degrees then the start value should be 45 degrees 60 degrees is stopped Start temperature stop temperature cooling mode For example want to control greenhouse cooling ventilation fans start when higher than 35 degrees down 32 degrees when you stop you start value should be set to 35 stop value is set to 32 SET Function keys Off button 1 In the boot state press SET 3s can shutdown shutdown if the power remains off2 Press SET to power in the off state after boot if the power remains switched on3 Short press SET to switch module temperature intermittent operationreservation Power Off Timer F
