XH-M601 Battery Charging Control Module 12V Intelligent Charger Power Control Panel Full Power Off Overcharge Protector

Specifications Product name Battery Charging Control ModuleProduct model XH M601Supply voltage 13 8V 14 8VRelay closing voltage 12 4VRelay disconnection voltage 14 8VVoltage error ±0 1VVoltage detection method DC voltmeterCharging type 12V batteryPotentiometer adjustment RP1 RP2 careful adjustment Product Size 50 32 18mmFeatures 1 This board is specially designed for 12V battery when the battery voltage drops to about 12 4V low voltage adjustable the protection board will automatically perform secondary charging and when the power is turned off about 14 8V M cut off voltage adjustable Charging When the red light is on the red light is off when fully charged and the relay disconnects the 220V terminal to end the charging thus achieving the effect of energy saving 2 This board is suitable for 1 2KW transformer the battery can be woken up by the protection board to detect high level and low level to automatically manage charging 3 This board has reverse connection protection function no output if the battery is not connected no matter whether the battery clips at the output end touch or not you can plug in with confidence No output if the battery polarity is reversed This is a very practical function and even a blind person will not have a problem Output short circuit automatic shutdown This is also a very practical protection no matter what state the charger is in as long as the output terminal is short circuited the charger will automatical
