Wooden Camera Unified Accessory Kit for ARRI Alexa Mini Camera (Advanced)
The ARRI Alexa Mini Unified Accessory Kit (Advanced) is a professional camera support package designed for the ARRI Alexa Mini camera. The Alexa Mini accessory package includes: Unified Cage (Alexa Mini + LW), a form fitting cage with quick release NATO rosettes and threaded holes for accessory attachment, a camera baseplate for holding two15mm Rods (15") at the correct lens height, NATO Handle Kit (Plus, 100mm), a quick release handle that attaches to the top plate, has a rotating top grip, multiple mounting points for accessories, integrated shoe mount and a 15mm/19mm rod opening, the Safety Dovetail (12") which is an ARRI standard dovetail that interfaces with the Unified Baseplate's ARRI dovetail slot on bottom, Rod Clamp (15mm LW), a mount that holds the Battery Slide, an adjustable battery plate for attaching a V-Mount or Gold Mount plate to the camera onto the 15mm rods. Unified Cage (Alexa Mini+LW) Unified Cage (Alexa Mini + LW) is a form fitting cage plus 15mm lightweight baseplate for the ARRI Alexa Mini. It attaches by four M4 screws on top and four M4 screws on the bottom making it extremely secure. The same M4 hole pattern found on the camera body is present on the cage top plate. This allows for attachment of ARRI brand handles and accessories. Arrays of 1/4-20 holes in standard spacing and multiple 3/8-16 holes for large accessories. ARRI accessory mount also available in several places (3/8-16 screw hole with locating pins adjacent). The cage side pieces feature NATO standard accessory rails with spring loaded safety pins on each end to prevent accidental removal. The NATO rails also feature 1/4-20 and 3/8-16 holes. Clamped to the side rails are two NATO Rosette (ARRI) which adapt an ARRI standard rosette to quick release NATO rail. Unified Cage (Alexa Mini + LW) also includes a lightweight 15mm support baseplate that allows for 15mm pass through rods. The bottom of the baseplate is comprised of the Lower Quick Dovetail which has 1/4-20 and 3/8-16 threaded holes for attaching to tripod plate or ARRI standard bridge plate such as Unified Bridgeplate (19mm) or Unified Bridgeplate (15mm Studio). To remove the camera from the included Lower Quick Dovetail and take the 15mm lightweight rods with you, unlock the left thumbscrew, slide the baseplate backwards a short distance and lift up. This action exposes an integrated ARRI dovetail slot on the bottom which can attach directly to any 2060 Dovetails, Safety Dovetails, or Shoulder Rigs. For VCT-14 compatible mounting options, the Unified Cage can be attached to the Unified VCT Wedge Plate, providing easy counterbalance ability while on the shoulder. This could then be attached to the Unified VCT-14 Tripod Plate which would be attached to the tripod head. 15mm Rod 15mm diameter iris rods used for mounting accessories like follow focus, matte box, lens support, servo motors and more. NATO Handle Kit (Plus, 100mm) The NATO Handle Kit (Plus, 100mm) is a quick release top handle that attaches and detaches without screws. Includes NATO Handle (Plus) and Safety NATO Rail (100mm) at a reduced package price. To attach to camera, slide onto NATO rail and turn thumbscrew to lock in place. Loosen top knob to adjust grip rotation. Sideways 15mm tube clamp allows for attachment of UVF Mount v2 (No Clamp). Forward facing 15mm rod opening and 19mm rear rod opening for attaching single rods for focus motors, etc. Integrated shoe mount for attaching on camera lights, microphone shock mounts, etc. 1/4-20 and 3/8-16 holes on grip area for attaching additional accessories. 1/4-20 holes on handle front for attaching Rod Clamps which allow for pass through rods front to back. Safety NATO Rail (100mm), included in kit, attaches to two 1/4-20 screw points spaced up to 72mm apart center to center. Safety Dovetail (12") 12" ARRI standard dovetail with safety catch on one end to prevent accidental camera removal. Threaded 1/4-20 and 3/8-16 holes for accessory mounting and tripod attachment. Attach to Shoulder Pad for custom handheld configurations. Perfect for Manfrotto, Miller, Cartoni and more. Rod Clamp (15mm LW) Rod Clamp (15mm LW) can attach to existing 15mm rods to provide 1/4-20 mounting points. It can also be turned over and bolted to cheeseplates, cages, battery plates and more. Extremely versatile, compact and lightweight. Battery Slide Battery Slide is an adjustable mounting system for WC V-Mount, WC Gold Mount, QRC Gold Mount and RED/Blueshape style battery plates. Rows of pass through holes allow attachment of Rod Clamps, cheeseplates and more. Apply firm pressure to tilt the plate in place. Loosen the thumbscrew to slide the plate up and down and also tilt. Great for adjusting counterbalance and for transitioning from studio to handheld mode.
