Wideband Low Noise Amplifier Module 35dB Gain 0.6dB Noise Figure 1.1-1.7GHz forSatellite Navigation GPS GLONASS Beidou G

Specifications Frequency Range 1 1 1 7 GHzTypical Gain 35 dBGain Flatness ±0 5 dBNoise Figure 0 6 dBOutput Power 20 dBm 1 dB compression point Operating Voltage DC 5VOperating Current 130 mAInput Output Impedance 50 ΩConnector Type SMA K Female or custom options based on demandDimensions 35 mm x 22 mm x 11 mm LxWxH Weight Approx 22 gFeatures 1 Ultra low Noise PerformanceWith a noise figure of only 0 6 dB this amplifier captures weaksatellite signals while significantly reducing background noise 2 High Gain CapabilityOffers a robust 35 dB typical gain ensuring strong signal amplification for enhanced receiver sensitivity 3 Broad Frequency RangeDesigned to cover 1 1 to 1 7 GHz seamlessly compatible with Beidou GPS GLONASS and Galileosatellite navigation systems 4 Exceptional Signal QualityFeatures a 20 dBm output power at 1 dB compression point maintaining signal fidelity even in the presence of strong in band interference 5 Easy IntegrationStandard 50 Ω impedance with SMA K connectors and compact dimensions 35mm x 22mm x 11mm make it simple to incorporate into various RF systems Package Included 1 x Low Noise Amplifier LNA Module
