Waveshare e-Ink Display Screen Driver Board SPI Interface Compatible with 3rd Generation B/Zero/Zero For Arduino

Note: This product does not contain any electronic ink screen module. Features: Based on standard interface design, compatible and directly insertable Raspberry Pi 2 generation B/3 generation B/Zero/Zero W Introduce SPI control interface, can access Raspberry/Arduino/Nucleo and other main control boards Provide a complete supporting information manual (sample programs such as Raspberry/Arduino/STM32) Parameter: Working voltage: 3.3V Communication interface: 3-wire SPI, 4-wire SPI Dimensions: 65mm 30.2mm Fixed hole diameter: 3.0mm Interface Description: VCC: 3.3V GND : GND DIN: SPI communication MOSI pin CLK: SPI communication SCK pin CS : SPI Chip Select Pin (Active Low) DC: Data/command control pin (high level means data, low level means command) RST : External reset pin (low reset) BUSY: Busy status output pin (low level means busy) Information includes: User manual Schematic Sample program Development materials Package includes: 1 x e-Paper Driver HAT 1 x RPi copper column package (2PCS set) 1 x PH2.0 8PIN cable 20cm
