Waveshare UART TTL to Ethernet Converter Module M0 series 32-bit ARM processor 10/100M Auto-MDI/MDIX ethernet interface

Waveshare UART TTL to Ethernet Converter Module M0 series 32-bit ARM processor 10/100M Auto-MDI/MDIX ethernet interface
thumb
thumb
thumb
thumb
thumb
thumb
sku: 32763137234
$23.65
Shipping from: China
   Technical Details
Brand Name: Waveshare
Demo Board Type: ARM
Dimension: 50.5 x 22.6 x 15 (mm)
Interface: 3.3V TTL (2.54mm pitch pinheader)
Model Number: UART TO ETH
Operating Current: 150mA (avg)/160mA (max)
Operating Temperature: -25~75 Celsius
Power Consumption: <1W
Power Supply: 3.3V DC or 5V DC (via different pin)
Protection: built-in 1.5KV electromagnetic isolation
Storage Condition: -40~105 Celsius, 5~95%RH
Type: UART TTL to Ethernet Converter
