Waveshare OV5640 Camera Module 5 Million 2592x1944 Development Board STM32 Camera Auto Focus Flash

Introduction: Based on the OV5640 camera module, 5 million pixels, image resolution up to 2592x1944. With auto focus support, you can automatically adjust the focus according to the distance of the object. Support flash function, no longer worry about the light is too dark, can not shoot the picture. Parameter: Image: 5 million Resolution: 2592x1944 Photosensitive chip: OV5640 High sensitivity, low crosstalk, low noise with 1.4um x 1.4um pixel OmniBSI technology Supports automatic exposure, auto white balance, automatic elimination of light streaks, automatic black level calibration, and automatic bandpass filters Support color saturation adjustment, tone adjustment, gamma correction, sharpness and lens calibration Support for image scaling, panning, and window settings Support auto focus Flash support Camera: CCD size: 1/4 inch Aperture (F): 2.8 Focal Length: 3.37mm (adjustable) Diagonal angle: 67.4 degrees Output format: YUV(422/420)/YCbCr422 RGB565/555/444 CCIR656 RAW RGB Compressed Data Working voltage: 3.3V Control interface: SCCB (compatible with I2C) Data interface: DVP 8 bit Size: 35.70mm 23.90mm Information includes: Circuit schematic Sample programs (STM32F4 and STM32F7) User manual Package includes: 1 x OV5640 Camera Board (C)
