Waveshare 23950 Industrial Serial Server RS232 to RJ45 Ethernet TCP/IP to Serial

1. Product type: serial server, Modbus gateway, MQTT gateway2. Basic functions: bidirectional transparent data transmission between RS232 and Ethernet3. Communication interface: RS232 port x 1, Ethernet port x 14. Power supply: DC 6 ~ 36V5. Ethernet: ordinary network port PoE network port; support IEEE 802.3af standard; 10 / 100M auto-negotiation RJ45 connector, 2KV surge protection6. Baud rate: 300 ~ 115200 bps7. Parity bit: None, Odd, Even, Mark, Space8. Data bits: 5 ~ 9 bits9. Flow Control: N/A10. Protocol: Ethernet, IP, TCP, UDP, HTTP, ARP, ICMP, DHCP, DNS11. Configuration: host, web browser, device management function library12. Communication method: TCP/IP direct communication, VCOM13. Operation mode: TCP server, TCP client (coexist with TCP server), UDP, UDP multicast14. Dimensions: 87x36x59mm15. Easily combine multiple DIN rail serial servers, more freedom16. Two-way transparent data transmission between RS232 and Ethernet17. Suitable for Modbus Gridding upgrade, can be used with specific configuration software18. MQTT/JSON to Modbus, more flexible conversion between different protocols19. Multi-host polling support, different network devices will be recognized and responded separately, and there will be no crosstalk problems when communicating with multiple network devices20. Multi-host polling support, easy cloud communication and device identification21. NTP protocol support, obtain network time information for serial output or data upload22. Multiple configuration methods, support web browser configuration, obtain dynamic IP through DHCP, and connect to domain server address through DNS protocol
