Waveshare® e-Paper Electronic Paper ink Screen Driver Board Expansion Board compatible with NUCLEO For Bare Screen

Documents Manual Click here to openSchematic Click here to openCode Click here to openOverview This is a universal driver board for connecting ARDUIN0 NUCLEO and e Paper raw panels can be used to drive various SPI interface e Paper from Waveshare Features Standard ARDUIN0 connectivity compatible with host boards like UNO Leonardo NUCLEO XNUCLEOOnboard voltage translator compatible with 3 3V 5V MCUsOnboard external RAM more available spaceMicro SD slot images can be stored on TF card for displayingReserved control interface for connecting with other control boards liComes with development resources and manual examples for ARDUIN0 STM32 Specifications Operating voltage 3 3V 5VInterface 3 wire SPI 4 wire SPI default RAM size 1M bit 128K byteOutline dimension 53 34mm 53 34mmInterface PINARDUIN0 NUCLEO PINDESCRIPTIONVCC5VPowerGNDGNDGroundSCKSCKSPI clock inputMOSIMOSISPI data inputMISOMISOSPI data outputEPD CSD10e Paper chip selectionEPD DCD9e Paper data commandEPD RSTD8e Paper resetEPD BUSYD7e Paper busySD CSD6SD card chip selectionSPIRAM CSD5SPI RAM chip selection Package includes 1 x Driver Board
