Waveshare® PL2303 USB UART Board Communication USB to TTL USB to Serial Mini Module

Waveshare® PL2303 USB UART Board Communication USB to TTL USB to Serial Mini Module
Waveshare
sku: 1701820
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$9.99
Shipping from: China
   Description
Features Using PL2303TA compatible with PL2303HXA Support windows XP 7 8 8 1 10 Support 3 power supply modes 5V external power supply 3 3V external power supply external power supply requires 3 3V 5V With 3 LEDs TXD LED RXD LED POWER LEDInstructions for use Take access to MCU as an example VCCIO output 3 3V or 5V module is powered by USB jumper cap must be jumped to 3 3V or 5V GND Connect to GNDTXD Connect to MCU RX Signal flow direction MCU RXPL2303PC TX RXD Connect to MCU TX Signal flow direction MCU TXPL2303PC RX Note The module is from USB to TTL level do not connect directly to RS232 level otherwise the module will be burned Documents Schematic Click here to openPL2303TA Click here to openPackage includes 1 x USB to Serial Mini Module
