Waveshare® 2.13 Inch E-ink Screen Display e-Paper Module SPI Interface Partial Refresh For Arduino

File download: www.waveshare.net/wiki/2.13inch e-Paper HAT Features: No backlight required, power off can keep the last screen display for a long time Very low power consumption, basically only consumes power when refreshing For Raspberry Pi 2 Generation B/3 Generation B/Zero/Zero W Reserved SPI control interface pad for easy access to main control boards such as Arduino/Nucleo On-board level shifting chip compatible with 3.3V and 5V microcontroller interfaces Provide a complete supporting information manual (sample programs such as Raspberry/Arduino/STM32) Parameter: Working voltage: 3.3V/5V Communication interface: SPI Dimensions: 65mm 30.2mm Display size: 48.55mm 23.71mm Dot Distance: 0.194 0.194 Resolution: 250 122 Display color: black, white Gray level: 2 Partial refresh: 0.3s Global refresh: 2s Refresh power consumption: 26.4mW (typ.) Standby power consumption: 170 Interface Description: VCC: 3.3V/5V GND : GND DIN: SPI communication MOSI pin CLK: SPI communication SCK pin CS : SPI Chip Select Pin (Active Low) DC: Data/command control pin (high level means data, low level means command) RST : External reset pin (low reset) BUSY: Busy status output pin (high level means busy) Package includes: 1 x 2.13inch e-Paper HAT 1 x RPi copper column package (2PCS set) 1 x PH2.0 8PIN cable 20cm
