Waveshare® 1.54 Inch Ink Screen 200x200 Bare Screen Electronic Paper Display SPI Interface Red Black and White Three Col

Documents Manual Click here to openSchematic Click here to openDatasheet Click here to openOverview This is an E Ink raw display 1 54inch 200x200 resolution with embedded controller communicating via SPI interface supports red black and white three color display Due to the advantages like ultra low power consumption wide viewing angle clear display without electricity it is an ideal choice for applications such as shelf label industrial instrument and so on Features No backlight keeps displaying last content for a long time even when power downUltra low power consumption basically power is only required for refreshingSpecifications Operating voltage 3 3VInterface 3 wire SPI 4 wire SPIOutline dimension 31 8mm 37 32mm 1 05mmDisplay size 27 6mm 27 6mmDot pitch 0 138 0 138Resolution 200 200Display color red black whiteGrey level 2Full refresh time 8sRefresh power 26 4mW typ Standby power 0 017mWViewing angle 170°Interfaces VCC3 3VGNDGNDDINSPI MOSICLKSPI SCKCSSPI chip select Low active DCData Command control pin High for data and low for command RSTExternal reset pin Low for reset BUSYBusy state output pin Low for busy Package includes 1 x 1 54inch e Paper B
