WS2812B-4 5V 5050 RGB LED Lamp Panel Board 4-Bit Full-color Driver Module Development Board

Feature: Intelligent reverse polarity protection, power supply reverse polarity will not damageIC. ICAnd a control circuitLEDA point light utility power . And a control circuitRGBIn a chip5050Package components constituting a complete external control pixels. Built-in signal shaping circuit any one pixel signal is received through the waveform shaping and then output to ensure line waveform distortion will not accumulate . Built-in power-on reset and brown-out reset circuit . Trichromatic color of each pixel can be realized256Brightness display complete16777216Colors all true color display scanning frequency of not less than400Hz / is. Serial cascade interface through a signal line finish receiving and decoding data. Pass any two points in the transmission distance of not more than5Without adding any circuit meters. When the refresh rate30frame/Second, the number of cascades of not less than1024point. Data transmission speeds of up to800Kbps. Light color highly consistent cost-effective . Size:15 * 15 Application: LEDFull-color light-emitting character string lights% 2C LEDFull-color module ,ledFull Color Flexible Strip Light Bar% 2C LEDGuardrail . LEDpoint Light% 2C LEDPixel screen% 2C LEDShaped screen a variety of electronic products, electrical equipment marquees . Product Description: 1. WS2813BIt is a set of control circuit and lighting circuit in one of the intelligent external controlLEDlight source. Its shape and a5050LEDSame lamp beads, each element is a pixel . Pixels contained within an intelligent digital interface data latch signal shaping amplification drive circuit further includes a high-precision internal oscillator and12VProgrammable high voltage constant current control section ,Effectively guarantee the color of the pixel spot light uniform height. 2. NRZ data protocol uses a single line of communication, the pixels on the POR,DINReceives data transmitted from the controller over the first sent over24bitAfter the data is first extracted pixel to the pixel data of the internal latch the remaining data after the shaping process through the internal circuit is amplified by shapingDOOutput port begins forwarding to the next cascaded pixels each pixel through a transmission the signal reduction24bit. Pixel using automatic forwarding shaping technology, making the number of pixels of the cascade unlimited signal transmission signal transmission speed is only limited . 3. LEDHaving a low-voltage driving environmentally friendly energy high brightness, large angle scattering consistency low power, long life and other advantages . The control circuit is integrated inLEDAbove, the circuit becomes more simple, small easy to install even more . Package Included: 1 x WS2812B-4 5V 5050 RGB LED Lamp Panel Board
