WINTACT WT2100 Coating Thickness Gauge Handheld Digital Measuring Paint Thickness Data Logger

Description This product is a color screen portable coating thickness gauge with high definition display It can quickly non destructively and accurately measure the thickness of non magnetic coating such as paint electroplate thin film etc on magnetic metal substrates It is widely used in manufacturing metal processing chemical industry commodity inspection and other testing areas Functions Menu operate and color screen HD display Non magnetic coating thickness measurement on magnetic metal substrate surface Two measurement methods single measurement continuous measurement Three calibration modes basic offset zero calibration Metric imperial unit and storage function Screen rotation charge protection multi interface displays screen brightness selection Automatic shutdownSpecifications Model WT2100Material ABS PlasticSensor Probe Type FeWorking Principle Magnetic Induction Fe Range 0 1800um 0 70 9mil 0 1 8mmUnits μm mil mmAccuracy ±5um ≤150um ± 3 H 1um 150um Resolution 0 1um 100um 1um ≥100um 0 1mil 0 001mmMinimum Diameter of Magnetic Metal Substrate 12mmMinimum Thickness of Magnetic Metal Substrate 0 5mmMinimum Radiu of Curvature for Magnetic Convex Substrate 2mmMinimum Radiu of Curvature for Magnetic Concave Substrate 11mmData Storage 15 Groups total 1500 data storageOperate Temperature 0 50℃Power 3x1 2V Ni MH battery weight 36 5g or 5V1A power adapterSize 70 30 38 6 149 59mmWeight 136 9 with batteryPackage included 1 x Coating T
