WAVESHARE 5-Inch DSI Capacitive Touchscreen IPS Tempered Glass Panel, Specification: Standard

1. Supports software-controlled backlight brightness2. IPS display panel, excellent display performance, 178-degree viewing angle3. Supports five-point touch; actual touch points depend on the software system4. Tempered glass panel, hardness up to 6H5. Fully laminated screen, high clarity, dustproof6. Default display is portrait mode, resolution is 720 x 1280 (HxV), landscape mode can be configured via software settings7. Supports Raspberry Pi OS, five-point touch; ESP32-P4 supports LVGL custom screen, five-point touch; RK3506 supports Buildroot, Ubuntu, etc., five-point touch; RK3576 supports Buildroot, Debian, Ubuntu, Android, etc., five-point touch8. Note: The version with a case only supports Raspberry Pi 5Standard version:1. 5-DSI-TOUCH-B touchscreen x 12. MIPI-DSI-Cable-12cm x 13. MX1.25 2PIN to 2.54 3PIN cable x 14. FFC cable 22PIN 200mm (reverse direction) x 15. FFC cable 22PIN 100mm (reverse direction) x 16. MX1.25 2PIN to MX1.25 4PIN approx. 150mm x 17. Copper pillar case x 1Casing version packaging:1. 5-DSI-TOUCH-B touchscreen x 12. Black casing x 13. MIPI-DSI-Cable-12cm x 14. MX1.25 2PIN to 2.54 3PIN cable x 15. FFC cable 22PIN 200mm (reverse direction) x 16. 7. FFC cable 22PIN 100mm (reverse direction) x 18. MX1.25 2PIN to MX1.25 4PIN approx. 150mm x 19. DSI-Cable-12cm-C x 110. Silicone button x 111. Copper pillar bag x 112. Screw bag x 1
