W2026C DC 24V 10A Digital Hygrometer Humidity Meter with Red/Blue LED Display Hygrometer Adjustable Humidity Controller Sensor Switch

Specifications: Control humidity range: 1%RH-99%RH Load power: 10A/DC24V Humidity measurement range: 1% RH-999% RH Measurement error:3% RH (good environment temperature is 25) Control humidity accuracy: 1% RH display: 1% RH Humidity return: adjustable between 1-50% RH Supply voltage: DC24V Output type: 10A relay output Probe type: humidity resistance sensor Size: 48*29*22mm Installation hole: 46*27m Moisture control object: dehumidification or humidification Probe line length: 1.5m line length Working environment: humidity 90% RH no frosting Parameter Code and Settings: Code Description range Factory settings P0 Humidification/dehumidification H/C C P1 Backlash 1-50%RH P2 Set the maximum limit 99 95 P3 Set the minimum limit 1 5 P4 Temperature correction -10 10 P5 Delayed start 0-10 1 P6 Restore Factory settings ON- OFF OFF Setting Instructions: 1.Connect the power supply and load to power the controller. The red color above shows the humidity, blue below is displayed as the desired humidity 2. Press STG (+) ENT (-) to set the required humidity,After the setting is completed, wait for 3 seconds to automatically confirm the return. At this time, the controller automatically performs relay energization according to the setting. 3. Press and hold SET for 5 seconds to enter the main menu settings, press SET (+) ENT (-) to switch P0-P8, when adjusting parameters P0-P8 parameters 4. If you need to adjust P0, press SET button (+) ENT (-) at the same time, adjust 0K, then control SET (+) ENT (-) Note: For 10A relays, to meet high power loads, please make sure the line is correct. Indicator Description: Indicator light: off means the relay is off, steady light means the relay is closed Digital tube: The above shows that LL is the sensor open circuit, indicating that HH is out of the measurement range, the humidity will forcibly open the relay. Package Included: 1 x W2026C DC 24V 10A Digital Hygrometer Humidity Meter
