V03HW Car WIFI_OBDII Scanner PICI8F25K80 Main Control Chip Diagnostic Tools for Android Windows IOS

Feature 1 Small volume and highest integrated chip with independent appearance patent utility model patentand software copyright CE FCC RoHS certification2 The software can do the following 3 Read error diagnostic codes generic and manufacturer specific and show their meaning the databasehas more than 3000 common code definitions 4 Clear the error code and close the MIL check engine indicator 5 Display current sensor data including 6 Engine RPM RPM 7 The calculated load value8 Cooling temperature9 Fuel system status10 The speed of the car11 Short term fuel situation12 Long term fuel situation13 Intake manifold pressure14 Fuel injection advance time15 Inlet temperature16 Air for velocity17 Absolute position of throttle valve18 Oxygen detection voltage associated with a short term fuel state19 Fuel system status20 Fuel pressure21 There are many other data on fuel consumption monitoring Agreement Support OBDII Supported Agreement 1 SAE J1850 PWM 41 6Kbaud 2 SAE J1850 VPW 10 4Kbaud 3 ISO9141 2 5 baud init 10 4Kbaud 4 ISO14230 4 KWP 5 baud init 10 4 Kbaud 5 ISO14230 4 KWP fast init 10 4 Kbaud 6 ISO15765 4 CAN 11bit ID 500 Kbaud 7 ISO15765 4 CAN 29bit ID 500 Kbaud 8 ISO15765 4 CAN 11bit ID 250 Kbaud 9 ISO15765 4 CAN 29bit ID 250 Kbaud Specification SSIDWIFI OBDII Port35000Main Control ChipPICI8F25K80The Software PlatformSupport Android Windows IOSWorking Voltage9V 16VWorking Current65mAStandby Cu
