V03H2 Car OBDII Scanner bluetooth 2.0 Auto Tester Diagnostic Tools for Android Windows Symbian

Feature: 1. Small volume and highest integrated chip, with independent appearance patent, utility model patent and software copyright. CE, FCC, RoHS certification 2. The software can do the following: Read error diagnostic codes - generic and manufacturer specific, and show their meaning (the database has more than 3000 common code definitions) Clear the error code and close the MIL (" check engine "indicator) 3. Display current sensor data, including: 1. Engine RPM (RPM) 2. The calculated load value 3. Coolant temperature 4. Fuel system status 5. The speed of the car 5. Short-term fuel situation 6. Long-term fuel situation 7. Intake manifold pressure 8. Advance time of oil injection 9. Inlet temperature 10. Air flow velocity 11. Absolute position of throttle valve 12. Oxygen detection voltage associated with short-term fuel state 13. Fuel system status 14. Fuel pressure 15. There are many other data on fuel consumption monitoring... 4. Future features of the software: 1. Data graph display and log 2. Frozen frame data 3. Continuous and discontinuous oxygen detection results Agreement Support: OBDII Supported Agreement: 1. SAE J1850 PWM (41.6Kbaud) 2. SAE J1850 VPW (10.4Kbaud) 3. ISO9141-2(5 baud init, 10.4Kbaud) 4. ISO14230-4 KWP (5 baud init, 10.4 Kbaud) 5. ISO14230-4 KWP (fast init, 10.4 Kbaud) 6. ISO15765-4 CAN (11bit ID, 500 Kbaud) 7. ISO15765-4 CAN (29bit ID, 500 Kbaud) 8. ISO15765-4 CAN (11bit ID, 250 Kbaud) 9. ISO15765-4 CAN (29bit ID, 250 Kbaud) Specification: SSID OBDII Communication Methods bluetooth 2.0 Main Control Chip PICI8F25K80 The Software Platform Support Android, Windows Working Voltage 9V-16V Working Current 35mA Standby Current 25mA Working Temperature -40-85 Working Humidity
