Universal LED Display Booster Board Constant Current Backlight Driver Board High Voltage Strip For 10-24 Inch Screen

Feature: Size: 22x120mm, mounting hole distance: 110mm Input power: DC 12V Output voltage: LCD screen with voltage requirements of 20-55V or less. The backlight can theoretically be driven. The specific output power depends on the screen (it will automatically match the output power) Output current: 240mA or so Working temperature: -10 ~ +50 degrees Celsius Storage temperature: -20 ~ +70 degrees Celsius Compatible driver screen size: 15-24 inch LED LCD screen (the interface can be driven) LED backlight Light bar interface: 1 PH2.0-4PIN interface; 1 PH2.0-2PIN interface Note: This booster board is only equipped with one input power supply line, and does not distribute the output line connected to the LCD screen. High-pressure strip modification instructions: 1. Connect the power supply, ground, and switching signals required by the booster board to the general-purpose LED boost board. VCC power-on ON switch signal ADJ completion control GND ground Tip: The same method as the LCD high voltage board connection 2. How many lines are used to supply the LED light bar connection line with the multimeter? Which number of negative lines are the number of lines, which are only the positive and negative points, and the technology should not be used. The light bar can be seen and defined. Tip: The power supply of the LED strips are the same. How many sets of series circuits are connected together? How many sets of series circuits? Example: 3-4+ 3- (6 sets of series circuits) Reserved interface: 69*2 79*1 10P*2 12P*2 Not all interfaces are soldered on top, we pre-install one or more details please see the above description. Package includes: 1 x Universal LED Display Booster Board
