Universal Car Boat LED Key Ignition Switch Panel Barrel Engine Start 2-Position

Specification: Faceplate: Nylon Switch Ratings: DC 12V Panel Rating: 10 A Product Dimensions: (W x H) 69 x 69mm Mounting Depth: 45mm Panel Cut-out: diameter 40 mm Installation Instruction: 1. Disconnect all power(AC& DC) Disconnect positive cables from all batteries and AC shore power cord from the yacht. 2. Cut opening for mounting location,Using the mounting dimensions provided to measure and cut out the mounting hole in the surface where the panel is to be mounted. 3. Connect Positive and Lamp negative feed wire Connect the DC power source(the batteries) to the screw terminal away from the LED. Then connect the LED negative wire (black) to a DC negative bus bar. 4. Connect the LED positive wire and devices,Connect the LED positive wire (red) to screw,terminal near the LED. Connect the device or distribution panels to the same screw terminal. 5. Mount the switch panel Clean the surface where the panel is to be mounted carefully. Place the panel and screw down the panel to the mounting surface as tight as possible with self-tapping screws. 6. Reconnect and Test Reconnect all the AC& DC powers to supply power to the panel. Turn on and off all branch circuits to check if the panel works normally. Package Included: 1 X Ignition Switch Panel
