USB To ESP8266 ESP-07 Wi-Fi Module Built-in Antenna 2.4G Serial Transceiver For ESP-07 Debugging Firmware Programming

Features: 1. USB to ESP-07 module has CH340G USB to TTL driver IC onboard, so you can easily use your computer to do ESP-07 functional debugging. 2. ESP-07 is Wi-Fi serial transceiver module, based on ESP8266 SoC.The SOC has Integrated TCP/IP protocol stack.It is TTL serial communication interface and its parameters can be set by AT command. It is very easy to design projects by AT command. 3. It is widely used in networking, smart home project when it is connected to the Wi-Fi router. It can be used for remote monitoring of home appliances, bedroom temperature and humidity, controlling home appliances and smart car by the mobile phone. Specificatons: - Working voltage: 4.5V - 5.5V (On-board 3.3v LDO Regulator) - Working current: 300mA(LDO regulator can supply) - Selectable working mode: On-board toggle switch. UART side for serial TTL debugging by AT commands, PROG for firmware programming - USB to serial TTL chip: CH340G - Logic level: 3.3V - Serial port baud rate: 115200 (default) can be modified to other values by AT command - Serial communication format: 8N1 - Antenna Type: Built-in ceramic antenna is available, and you can also use an external antenna. - Wireless Network Mode: station / softAP / SoftAP + station - Wireless criteria: 802.11 b / g / n -Button Type: On-board reset button - On-board switch to select UART mode or firmware update mode - WIFI Mode: WIFI @ 2.4 GHz, support for WPA / WPA2 security mode Package Included: 1 x USB To ESP8266 ESP-07 Wi-Fi Module Built-in Antenna
