USB Interface 10 Way 12Bit AD Sampling Data Acquisition STM32 ADC Module, 501 Original

Features: 1. Onboard STM32F103C8T6 main control chip.2. Onboard CH340 serial port to USB chip, easy to check AD sampling result via USB port on PC.3. Preset USRT serial communication interface, can connect MCU.Specification:Analog Input Channel: 10- channel single port inputSampling Voltage Input Range: 0-3.3VPower Voltage: 5V/3.3VResolution Rate: 12 bit (4096)Board Size: 50*33mm/1.96*1.29\\'\\'Using Introduction:1. Used on PC: install USB to serial port chip CH340 driver, and plug the module on the computer, IN0-IN9 connect sampling voltage positive, GND connects sampling voltage negative (common ground process); open the serial port debugging helper, select correct COM port and baud rate (115200), then check AD sampling result; the result updates 500ms per times, and users can modify this time on the basis of source code2. Used on MCU: if users want to obtain sampling data via external MCU, you can connect MCU 3.3V, RX, TX, GND with module 3.3V, TX, RX, GND. You can also use 5V to supply power for the module3. Update Firmware: if users want to modify the source code and program again, please operate as below: plug the module on computer USB, and plug the jumper cap on the 3V3 port (after finishing program, plug it back to GND); open the program software FlyMcu, open the hex file, set port number and baud rate, click \\\"start program\\\"; then clip the two ports of capacitor C9.Warm Tips:1. Sampling voltage input port IN0-IN9 can be all or partially connected; when certain channel has no sampling voltage input, then the certain channel output result will be a random value; null port can be modified as common I/O port2. Sampling rate should be no higher than 3.3V, or it will cause damage to the chip.Note: Please allow 1-3mm differs due to manual measurement.Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.
