UNI-T UTG9504T Arbitrary Waveform Generator 500MHz 4 Channels 2.5GSa/s 16-Bit Touchscreen Signal Generator SPI I2C UART

Specifications Max Frequency 500 MHzChannels 4Arbitrary Waveform Length 64 MptsMax Sampling Rate 2 5 GSa sVertical Resolution 16 bitsMinimum Edge Time ≤ 1 5 ns adjustable duty cycleMaximum Output Amplitude 20 VppDigital Protocol Output SPI I2C UARTScreen Display 10 1 inch capacitive touchscreen 1280 x 800 resolutionFeatures 1 High Precision Signal Generation With a maximum frequency of 500 MHz and 16 bit vertical resolution the UTG9504T ensures precise waveform output for advanced testing applications 2 Flexible Arbitrary Waveform Design Equipped with 64 Mpts arbitrary waveform memory and adjustable duty cycles this generator supports highly customized testing scenarios 3 Fast Sampling and Edge Performance Featuring a 2 5 GSa s sampling rate and a minimum edge transition time of ≤1 5 ns the UTG9504T offers high speed and accurate responses 4 Advanced Communication Protocol Outputs Supports SPI I2C and UART for seamless integration with digital systems during protocol development and verification 5 Enhanced Usability with Touchscreen Interface The 10 1 inch capacitive touchscreen with a resolution of 1280 x 800 provides intuitive navigation and clear visualization of waveform configurations Package Included 1 x UTG9504T Arbitrary Waveform Generator1 x Power Cord4 x BNC Cable1 x USB Cable
