UNI-T UTD1050CL Handheld Digital Oscilloscope Sampling Rate 200MS/S AC DC Voltmeter Ammeter Ohmmeter Capacitance Multime

Description UNI T s UTD1050CL handheld oscilloscope is a single channel portable device with a bandwidth of 50MHz and a sampling rate of 200MS s It is an ergonomic portable and general purpose instrument designed for engineers Features 1 Isolated USB2 3 5 inch TFT LCD Display Resolution 320Horizontal RGB 240Vertical pixels 3 High resolution and high contrast color LCD Color BlackWhite display for your option perfect for use outdoors with strong sunshine 4 Intelligent local or network software update 5 Unique waveform record storage and recall functions 6 Battery 7 4 V 3600mAh rechargeable lithium batter 7 19 types of auto measurements 8 3999 display count9 Voltage current resistance diode capacitance continuity measurements offered10 Measure current up to 10A 11 Extremely low internal resistance designed for current measurement ensuring better measuring accuracy 12 Independent multimeter and scope functions in one tool Specifications Model UTD1050CL Broadband 50MHz Channel 1 Sampling rate 200 MS s Rise Time ≤ 7ns Storage depth 12kpts Vertical scale V DIV 5mV div 20V div Time base scale seconds divisions 5ns div 50s div Storage method Settings waveforms bitmaps Trigger types Edge pulse width video slope Interface Mini USB Multimeter specifications Scope Accuracy DC voltage V 400mV 4V 40V 400V ± 1 5 AC voltage V 400mV 4V 40V 400V ± 1 2 5 DC current A 400 μA 4000μA ± 1 2 5 40mA 4000mA ± 1 5 4A ± 1 5
