UNI-T UT71D Professional Auto Range Intelligent Digital Multimeter

UNI-T UT71D Professional Auto Range Intelligent Digital Multimeter
UNI-T
sku: 964055
$161.39
   Description
Description : Professional UNI-T UT71D 2.9Inch LCD Auto Range Intelligent Digital Multimeter Brand Name : UNI-T Model Number : UT71D Color : Red + Grey Display : L2.9 Inch LCD Max display : 39999 Battery : 1 x 9V 6F22 (included for you) Data storage : 9999pcs AC frequency response : 100KHz Voltage testing input impedance : 2.5G ohm (DC 400mV) Dimensions : 200 x 93 x 40mm Measuring DC Voltage Range : 400mV/4V/40V/400V/1000V (0.025%+5) Measuring AC Voltage Range : 4V/40V/400V/1000V (0.4%+30) Measuring DC Current Range : 400uA/4000uA/40mA/400mA/10A (0.1%+15) Measuring AC Current Range : 400uA/4000uA/40mA/400mA/10A (0.7%+15) Measuring Impedance Range : 400ohm/4K ohm/40K ohm/400K ohm/4M ohm/40M ohm (0.3%+8) Measuring Capacitance Range : 40nF/400nF/4uF/40uF/400uF/4mF/40mF (1%+20) Celsius temperature : -40~1000 Celsius degree(1%+30) Fahrenheit : -40~1832 degrees Fahrenheit (1.5%+50) Frequency : 40Hz~400MHz (0.01%+8) Duty cycle : 10%~90% (1%+30) Specification : Basic Functions Range Best Accuracy UT71C UT71D UT71E DC Voltage 400mV / 4V / 40V / 400V/ 1000V (0.023% + 5) (0.023% + 5) (0.023% + 5) AC Voltage 4V / 40V / 400V / 1000V (0.4% + 30) (0.4% + 30) (0.4% + 30) DC Current 400uA / 4000uA / 40mA / 400mA / 10A (0.1%+15) (0.1%+15) (0.1%+15) AC Current 400uA / 4000uA / 40mA / 400mA / 10A (0.7%+15) (0.7%+15) (0.7%+15) Impedance 400ohm / 4Kohm / 40Kohm / 400Kohm / 4Mohm / 40Mohm (0.3%+8) (0.3%+8) (0.3%+8) Capacitance 40nF / 400nF /4uF / 40uF / 400uF / 4mF / 40mF (1%+20) (1%+20) (1%+20) Celsius -40~1000 C (1%+30) (1%+30) (1%+30) Fahrenheit -40~1832 F (1.5%+50) (1.5%+50) (1.5%+50) Frequency 40Hz~400MHz (0.01%+8) (0.01%+8) (0.01%+8) Duty cycle 10%~90% (1%+30) (1%+30) (1%+30) 4 ~20mA% 0~100% (1%+50) (1%+50) (1%+50) Power 2500W (2%+5) Special Functions 10A Fuse Auto range Current measurement alarm Function setting Voltage & Current Data storage 100 9999 100 Diode Continuity buzzer True RMS Frequency response Max / Min Mode Relative mwasurement Data hold USB data transmission Dual backlight display Full symbol display Auto power off Low voltage display Input impendence DC 200mV : 2.5G ohm, other : 10M ohm Max display 4000 Analog bar General Characteristic Battery 9V (6F22) LCD Size 73 x 50 mm Body Size 200 x 93 x 40 mm Standard Accessories UT71C / UT71D : Test probe, alligator clip, USB Interface transmission line, Software CD,etc UT71E : Test probe, alligator clip, USB Interface transmission line, Software CD, Power conversion socket, etc Package includes : 1 x UT71D Intelligent Digital Multimeter (Come with full kit accessories as pictures show) Details pictures :
