UNI-T UT139S UT139E UT139C UT139B UT139A True RMS Digital Multimeter Temperature Probe LPF Pass Filter LoZ Low Impedance Input

UNI-T UT139S UT139E UT139C UT139B UT139A True RMS Digital Multimeter Temperature Probe LPF Pass Filter LoZ Low Impedance Input
thumb
thumb
thumb
thumb
thumb
thumb
sku: 4000101728895
$55.50+1%
$55.93
Shipping from: China
   Technical Details
AC Current: 200μA/2000μA/20mA/200mA/2A/10A
AC Voltage: 20mV/200mV/2V/20V/200V/600V
Brand Name: UNI-T
Counts Display: UT139C/UT139E/UT139S
DC Current: 200μA/2000μA/20mA/200mA/2A/10A
DC Voltage: 20mV/200mV/2V/20V/200V/600V
Dimensions: 175 x 81 x 48.5mm
Display Type: Digital Display
DIY Supplies: Electrical
Duty Cycle: 0.1% to 99.9% (without UT139A)
LoZ ACV: Low Impedance Input (UT139E/UT139S only)
LPF ACV: Low Pass Filter (UT139E/UT139S only)
Measuring Capacitance Range: 9.999nF/99.99nF/999.9nF/9.999μF/99.99μ F/999.9μF/9.999mF/99.99mF
Measuring Resistance Range: 200Ω/2KΩ/20KΩ/200KΩ/2MΩ/20MΩ
Model Number: UT139S/UT139E/UT139C/UT139B/UT139A
NCV: UT139A/UT139B/UT139C/UT139E/UT139S
Operating Mode: A/M
Operating Temperature: 0 - 50 ℃
Temperature Test: -40C to 1000C (UT139C/UT139E/UT139S)
V.F.C: UT139A/UT139B/UT139C
