UNI-T UPO2102CS Digital Storage Phosphor Oscilloscope 1GS/s Sampling Rate 2 Channels 100MHz Bandwidth

Notice UNI T official website manual software download address https www uni trend com index phpFeatures 1 Standard configuration is 28Mpts storage depth per channel 2 Multi level waveform gray scale 3 Up to 65 000 frames of hardware real time waveform recording function 4 Independent time base of each channel is adjustable 5 Has a powerful waveform analysis function 6 Abundant trigger and bus decoding functions 7 Provide abundant peripheral interfaces Specifications Models UPO2102CSBandwidth100 MHzChannels2Sample RateIGS sMax Memory Depth32MptsWaveform Capture Rate30 000wfms sTime Base Scale2 ns div 50 s divInput Coupling IMΩ±1 13pF±3pF Vertical ScaleImV div 20V div IMΩ OC Gain Accuracy±3 Waveform Record65 000 FramesTriggerEdge Alternate Runt Super picture Nth Edge Delay Duration SetupHold Pulse Width Slope Video Pattern RS232 UART I2C SPI USBBus DecodeStandard Parallel Optional RS232 UAR1 I2C SPI USBWaveform OperationA B A B AXB A B FFT Editable AdvancedAuto MeasurementPeak Peak Value Amplitude Maximum Minimum Top Value Bottom Value Mean Average Root Mean Square Value Overshoot Preshoot Frequency Cycle Rise Time Fall Time Positive Pulse Negative Pulse Positive Duty Ratio Negative Duty Ratio Delay l 2 and Delay 2 lNumber of MeasurementsDisplay 5 measurements at the same timeMeasurement StatisticAverage Max Min Standard Deviation Number of MeasurementsFrequency Counter Hardware 6 bits counter Channels are sele
