Tieline Genie Distribution with WheatNet-IP Audio Codec

This version of the Genie Distribution codec includes a purpose-built Tieline WheatNet audio card, which also provides compatibility with the AES67 standard for AoIP interoperabilityGenie Distribution is the world's most powerful audio codec for IP audio distribution applications. It also supports a range of innovative solutions over connection transports including IP, ISDN and POTS.ApplicationsThis version of the Genie Distribution codec includes a purpose-built Tieline WheatNet audio card, which also provides compatibility with the AES67 standard for AoIP interoperability.The rear panel provides a WheatNet LAN interface for connecting the codec directly to a WheatNet-IP network. After connecting to the WheatNet-IP Environment, the codec can deliver superior quality IP audio over LANs, WANs, the internet, the satellite IP, 3G, 4G, Wi-MAX and Wi-Fi.Genie Distribution with WheatNet-IP is ideal for:• 3x bidirectional stereo connections, or• 2x stereo and 2x mono bidirectional connections, or• 1x stereo and 4x mono bidirectional connections, or• 6x mono bidirectional connectionsMultiple Backup OptionsGenie Distribution IP codecs have multiple levels of power, audio and network redundancy. The codec features dual Gigabit Ethernet ports, dual internal power supplies, automated audio silence detection and IP network backup solutions to ensure you're always on the air.An automated network failure detection feature provides switching to a backup IP LAN connection. You can also fail over to backup ISDN or POTS connections as required using optional ISDN or POTS modules.Genie Distribution can automatically switch between 4 backup audio sources to maintain program output at transmitter sites. Options include:• Connection audio• Icecast streaming client• Audio file backup• Hardware bypass of audio inputs to outputs if power failsSmartStream PLUS redundant streamingConnect two inexpensive IP links to codecs with SmartStream PLUS and stream simultaneous redundant data streams from dual Ethernet ports and deliver seamless redundancy when streaming over IP.Bond multiple interfaces with Fuse-IPImagine the peace of mind knowing you can bond 2 cellular data links from different Telcos and let Tieline's Fuse-IP technology automatically manage the data capability of each link!Audio• Robust DSP-based architecture designed for rock solid, mission critical STL audio• 24 Bit 96kHz audio sampling (32kHz audio quality)• WheatNet-IP LAN port and Sync/Stream LEDs• Up to three stereo or 6 mono WheatNet audio channels in/out• Bidirectional Mono, Stereo or dual mono connections• Distributing up to 6 bidirectional channels between two codecs• 3x bidirectional stereo connections• 2x stereo and 2x mono bidirectional connections• 1x stereo and 4x mono bidirectional connections• 6x mono bidirectional connections• Simultaneously distributing one, two, three or six separate IP multi-unicast audio streams to a maximum of 60 endpoints in total• Broadcasting up to 6 separate IP audio streams in multicast server mode and distributing each of these streams to unlimited endpoints over compatible IP networks• Uncompressed PCM audio plus the low-delay, cascade resiliant aptX Enhanced algorithm• Other popular algorithms including LC-AAC, HE-AAC v1 and v2, AAC-LD, AAC-ELDv1 and v2, Opus, MPEG II, MPEG Layer-3, Tieline Music and MusicPLUS, G.722 and G.711Connectivity• Dual 1 Gigabit (10/100/1000) Ethernet ports support automatic switching for redundancy• Connect over Wi-Fi using USB Wi-Fi dongles• Primary and backup audio over IP, ISDN and POTS• Automated failover to backup connections• Support for up to 4 output audio source fail over options• SmartStream PLUS dual redundant IP streaming:• Fuse-IP network bonding (data aggregation) of Ethernet ports or Ethernet and Wi-Fi• SIP (SDP) compatible with EBU N/ACIP 3326 for interoperability with other codec manufacturers• Deterministic SIP answering and call routing: Configure up to 6 SIP accounts and connect up to 2 SIP interfaces• Compatibility over ISDN with Worldcast, Prodys, Mayah, CDQ Prima, AETA, AEQ, Orban and more• Compatibility over ISDN using aptX Enhanced encoding with Worldcast, Prodys Prontonet and Mayah• Selectable fixed or automatic jitter buffer: 5 automated settings available to manage network connectivity and avoid dropouts (includes configurable min and max buffer settings)• Configurable Forward Error Correction (FEC)• Highly advanced error concealment strategies• Real-time IP connection packet statistics• Real-time POTS line quality and IP link quality displayed• Support for Line Hunt dialing/answering and caller IDs using Tieline IPOperation• Full hardware front panel interface including navigation, LCD display, PPM meters and dialing key pad• User-friendly HTML5 Toolbox Web-GUI enables codec configuration and control remotely over WANs.• Toolbox Scheduler supports loading/unloading, connecting and disconnecting programs• Auto switching, dual redundant internal AC power supplies• IPv4 & IPv6 compatible and ready• Asymmetric algorithmic encode/decode• Integrated alarm management including automatic silence detection• Low latency in-band RS-232 aux data channel• Configurable software rules engine via web-GUI for Control Port (4 inputs/outputs) functions, plus WheatNet-IP LIO compatibility• Upgrade firmware from USB sticks• Backup and restore configuration via USB sticks• Automated firmware upgrade notifications via Web-GUI• Support for multiple languages: English, Spanish, Portuguese and French• Backward compatible with all Tieline IP codecsSecurity• User name and password protection of codec and Toolbox Web-GUI• Support for SSL Security Certificate installation• SIP Whitelists and Blacklists allow filtering of SIP URIs and User Agents
