Tickas 250W 20A Constant Current Electronic Load Tester Multifunction Digital Electronic Load Meter Battery Capacity Tester Discharge Aging Power Supply Module

This electronic load tester with digital display can monitor voltage and current. It can complete discharging and aging and test the capacity of the battery. With cooling fan and fin heat sink it has rapid heat dissipation and can be used for a long time. Features: Constant current electronic load tester with maximum 100V load voltage/ 20A discharge current/ 250W discharge power. It s multifunction and can accomplish discharging and aging and test the capacity of the battery. It uses IR power tube and double high-ball bearing cooling fan with fin heat sink which is not afraid of dust and can provide rapid heat dissipation for long-term use; power redundancy is no less than 50% (25℃). Digital screen provides clear visual display easy to read; compared to LCD it is more resistant to high . Voltage and current wiring connectors are separated with appropriate connection it can eliminate the influence of wire resistance to voltage. 100% power burn-in in factory suitable for assembly of power adapter -automatic burn-in cabinet. Instruction: 1. Connect to power supply then power on to electronic load mode. Make sure it is at stop condition (knob clockwise is minimum) then connect the tested power supply to the input power port pay attention to the polarity. 2. Rotate knob to set the constant current. Note: Since it works openly there is no voltage and power limitation but normal work should be below 100V 250W. Specifications: Material: PCB + Aluminum Alloy Power Supply Voltage: DC (±5%) (Equipment supply voltage) Maximum Load Voltage: 100V Constant Current Discharge Adjusting : 0-20A Work Mode: Constant Current Mode Maximum Discharge Current Error: 0.7%-0.01A Maximum Discharge Power: 250W Item Size: 12.8 * 11.5 * 8.8cm / 5.04 * 4.53 * 3.46in Item Weight: 805g / 1.78lbs Package Size: 14 * 13 * 11.8cm / 5.51 * 5.12 * 4.65in Package Weight: 910g / 2.01lbs Package List: 1 * Constant Current Electronic Load Tester 1 * Cable 2 * Washer
