TV Logic LUM-550H 54.6" 16:9 4K Ultra HD IPS LCD HDR Video Monitor

The new LUM-550H has a true UHD 3840x2160 resolution and 700 nits brightness for excellent color reproduction and high level visualization. The LUM-550H charms everyone with upper class picture quality.Why LUM-550H ?True 10bit10bit color depth that supports 1.07 Billion ColorsConvenientSupports Various Professional FeaturesTrue UHDNative UHD Resolution (3840 x 2160)HDR EmulationHDR EOTFs of PQ HLG and SLog3Wide Color GamutColor gamut covers up to DCI-P3Versatile InterfaceSupports 12G/6G/3G/HD-SDI and HDMI 2.0 InterfacesFeaturesHDR Monitoring on the 600nits DisplayThe LUM-550H provides High Dynamic Range mode which allows for monitoring black and highlights on the screen at the same time. The LUM-550H supports PQ, HLG, SLOG3 as HDR EOTF gamma.Optimum Color SettingsIf you select the desired color standard among HD, UHD, DCI-P3, PQ Dolby PQ HLG, the pre-set values for each parameter are automatically applied to display the image in the optimum quality.UMD Display Displays user customized characters or source ID or Tally signal of Ancillary(ANC) data. • [UMD] mode : Displays user customized 8 characters• [ANC] mode : Displays characters embedded in SDI signal• UMD Character Color: Red, Green, Blue, Yellow, Cyan, Magenta, White• UMD Size: Small, LargeEETF (Electrical-Electrical Transfer Function)This function provides a toe and knee to gracefully roll off the highlights and shadows providing a balance between preserving the artistic intent and maintaining details.WaveformThe LUM-550H supports the various modes of Waveform monitor.VectorScopeThis function displays the color components 'B-Y' and 'R-Y' of the input signals onto X-Y axis. Two different types of VectorScopes are displayed according to SD or HD/UHD input signals. 100% and 75% scales are indicated on the VectorScope.Gamut WarningWhen using the monitor in HDR mode of BT.2020 color space, colors that are outside of the monitor's color gamut may be mapped onto the surface of the supported color scope with reduced saturation /brightness, while preserving the same color hue. Gamut warning function will show these mapped colors.Luma(Y') Zone CheckAnalyzes the Luma(Y') level of the input image and displays the selected zone on the screen. After each pixel's V' level is analyzed, it is displayed as a certain color or zebra pattern according to the Index on the right side of the screen.Focust AssistFocus Assist function assigns a color to the pixels in the shape or boundary area of the image to inform the user to make the best focus. With this function, user can easily differentiate the focused area from out-focused area especially shooting with shallow depth of field.Audio Level MeterDisplays the level of the embedded audio signal together with the video signal input through SDI and HDMI. Up to 16 channels are supported for SDI and 2 channels for HDMI.Various modes of Level Meter helps the user with the convenient audio monitoring.• Level Meter channel number(16ch, 8ch,) adjustable• Level Meter grouping available• Audio channel Pair or Group selectable• Level Meter size(Small, Normal, Large) changeableRange ErrorAnalyzes the input signal's Luma(Y') and chroma information(C') and if the input signal exceeds the designated minimum value and maximum value, the pixel shall blink. This function is to help the user to easily find out any unwanted level of signals and for better exposure setting.TimeCode DisplayDisplays the Timecode information on the screen. Supporting mode is [VITC] and [LTC]. MarkerThe LUM-550H has the various marker modes which allow the user to adjust Marker type, Center Marker, Safety Area, Fit Marker, Marker Mat, Marker Color, Marker Thickness, etc. Blue Only / MonoRed and Green channels are not used and only Blue or Monochrome channel is used to display the screen. This function is used to adjust the color tones (tones and saturation) of the screen using the SMPTE Color Bar. For example, after displaying the Blue channel, adjust the Color (or Saturation) and Tint (or Hue) so that the original Magenta and Cyan are of the same brightness, and the original Gray and Blue are of the same brightness.Closed CaptionWhen this function is set on, the monitor displays both speech and non-speech elements in the videos. (e.g. coughs, music, door slams, thunderstorm, dog barking, etc.) CC608(ANC), CC608(LINE21), CC708 are supported.H/V DelayThis function allows the user to check the blanking area and synchronize signals by displaying the horizontal and vertical intervals in the center of the screen.
