TV Logic F-5A 5.5" Full-Featured Field Monitor with FHD IPS-LCD

The F-5A is a compact and light-weight field production monitor with Full HD resolution of 1920 x 1080, nice viewing angle and max luminance of 500nit. Equipped with a new image processing engine, F-5A reproduces even better sharpness and peaking boost capability for focus pullers. It also supports various video formats via 3G-SDI and HDMI 1.3 interface. And also support professional features such as Waveform/Vectorscope, Focus Assist, 3D LUT import, Camera Logs and HDR emulation.5.5" Fully-featured Full HD field monitor5.5" compact and light-weight field production monitor that accommodates a wide scope of applications ranging from DSLR cameras to Professional Cinema Cameras for broadcast and movie productionSuper-Sharp DetailsUpgraded with the Sharpness + Peaking Boost function, the F-5A offers exceptional clarity and detail for focus pullersEasy Control, Versatile PortsThe F-5A offers convenient control with a scroll wheel and 3 x function keys and provides various video inputs including 3G-SDI and HDMIKey features Audio Level Meter Display Displays the level of the embedded sound signal together with the video signal input through the terminal such as SDI or HDMI.Blue Only / MonoRed and Green channels are not used and only Blue or Monochrome channel is used to display the screen. This function is used to adjust the color tones (tones and saturation) of the screen using the SMPTE Color Bar. For example, after displaying the Blue channel, adjust the Color (or Saturation) and Tint (or Hue) so that the original Magenta and Cyan are of the same brightness, and the original Gray and Blue are of the same brightness.Focus AssistAssigns a color to the pixels on the boundaries of the image to inform the user to achieve the best focus. With this function, user can easily differentiate the focused area from out-focused area especially when shooting with a shallow depth of field.H/V DelayAllows you to check the Blanking area and synchronize signals by displaying the horizontal and vertical intervals in the center of the screen.H/V FlipAllows the displayed image to be flipped horizontally or vertically. This feature provides flexible mounting options for camera operators.Key LockLocks the knob or key control.Luma(Y') Zone CheckDisplays the Luma(Y') level of the input image in colors. Each pixel's Y' analyzed and changed to a certain color or zebra pattern according to the Index on the right side of the screen.MarkerDisplays various kinds of aspect ratios on the screen. Wide range of markers and security areas are available with line color and curtain transparency selection. A User Marker is available if any of standard markers fits your requirements.Max Brightness On/OffDisplays the brightness increases from the normal up to max brightness to obtain a sharp and bright image when shooting outdoors.Range ErrorAnahlyzes the input signal's Luma(Y') and chroma information(C') and if the input signal exceeds the designated minimum value and maximum value, the pixel shall blink. This function is to help the user to easily find out any unwanted levels of signals and for a better exposure setting.Time Code DisplayDisplays the Timecode information on the screen.User AspectAdjusts the Width /Height display ratio.Various Scan ModesControls the size of the image. Overscan: Extra area around the four edges of the image that may not be seen reliably by the viewer. Underscan: Constrains the size of the image so the monitor shows everything the camera is seeing. 1:1 pixel: Displays the original image resolution without scaling to match a certain resolution or an aspect ratio.Waveform/Vector ScopeWaveform Y: Displays the Luma(Y'), Cb, Cr component of the input signal into waveform.Vector Scope: Displays the color components 'B-Y' and 'R-Y'of the input signals onto the X-Y axis.ZoomMagnifies the input signal from 0% to 90%.Camera LutApplies the LUTs to the outbound Log signal. A LUT for every major camera manufacturer has been included (LOG-C, C-LOG, S-LOG 1, 2, 3 and RED Gamma 3, 4).ARRI Alex Metadata over SDITakes the Metadata from the ARRI ALEXA is transported through the SDI outputs of the camera, and displays it on the monitor.Split ZoomZooms the specified area sequentially.Anamorphic DesqueezeSupports several formats and resolutions that are ideally suited for anamorphic lenses and aspect ratios. When shooting anamorphic the image you are monitoring is an "unsqueezed" preview of what's actually being recorded.Sleep ModeSets the LUMINANCE to the minimum value when the time set in the still image output is exceeded.
