TLV3501 High Speed Comparator Frequency Meter Front-end Shaping Module 4.5ns Ultra High-speed Comparator

Product application The TLV3501 is a single channel high speed push pull output comparator with a delay time of 4 5ns supply voltage 2 7V to 5 5V and an excellent range of input common mode range beyond the swing input making it ideal for low voltage applications Rail to rail outputs can be directly driven by CMOS or TTL logic The module can be used for shaping the wide voltage range and periodic signals and it is used as the front end conditioning module in time domain measurement such as frequency and phase difference Application 1 sine wave to Fang Bo 2 zero over comparator 3 general comparator Technical indicators 1 Supply voltage 2 7 5VDC2 Input voltage 10 1000mV valid value 3 Output level rail to rail output Direct driveTTL CMOSlevel4 Input frequency DC 200MHz5 Interface form SMA Header outside screw hole 6 Input impedance 50 Ohm7 Case with shieldMeasured waveform 1 1MHZ 1VPP sine wave input output waveform after comparator 2 10MHZ 1VPP sine wave input output waveform after comparator 3 50MHZ 1VPP sine wave input output waveform after comparator 4 100MHZ 1VPP sine wave input output waveform after comparator 5 150MHZ 1VPP sine wave input output waveform after comparator 6 200MHZ 1VPP sine wave input output waveform after comparator Package included 1 x TLV3501 High Speed Comparator
