TINYSOME WSFG-06 PWM Pulse Adjustable Module Sine Wave 4-20mA 2-10V Signal Generator for Pulse Mode

Features: The adjustable multi-function signal generator supports multiple modes such as PWM mode pulse mode signal source mode and sine wave mode. PWM mode: voltage frequency and duty cycle are adjustable for w/ an accuracy of up to 0.1%; voltage range: 1-24V frequency range: 1-150KHZ duty cycle range: 0-. Pulse mode: initial delay for time T0: 0-60S high level for time T1: 0-60S low level for time T2: 0-60S pulse number PulseNun: 1-60000. Signal source mode: voltage source 2-10V current source 4-20mA. Sine wave mode: 1-1000Hz. Powerful signal load capacity output current up to 30mA. Clear display easy control panel layout. Specifications: Item Type: Signal Generator Module Model: WSFG-06 Supply Voltage: 7-24V Product Function: PWM Mode Pulse Mode Source Mode Sine Wave Mode PWM Mode: Voltage frequency duty cycle are adjustable accuracy up to 0.1%; voltage range: 1-24V frequency range: 1-150KHZ duty cycle range: 0-100% Pulse Mode: Initial delay for time T0: 0-60S high level for time T1: 0-60S low level for time T2: 0-60S pulse number PulseNun: 1-60000 Signal Source Mode: Voltage source 2-10V current source 4-20mA Sine Wave Mode: 1-1000Hz Signal Load Capacity: Output current up to 30mA (Note: This product outputs signal source can not directly drive the high power load) Ambient Temperature: -10-+70°C Module Size: 79x43x41mm / 3.11x1.69x1.61in Opening Size: 76x39mm / 2.99x1.54in Note: Please allow 0-1cm error due to manual measurement. Make sure you do not mind before you bid. Due to the difference between different monitors the picture may not reflect the actual color of the item. Thank you! Package includes: 1 Pcs Signal Generator Module.
