TEC-06 Battery Capacity Testing 16W Electronic Load Tester with Case for Mobile Power Tester LED Display with Fan Cable

Description 1 TEC 06 is constant current electronic load It uses high precision DAC loop control technology to control output current for power supply or battery So that the current does not change with the voltage changes It is a load itself no longer need another external load discharge 2 This is a linear electronic load not a PWM mode3 TEC 06 will automatically calculate the product of discharge current and time to detect the battery capacity 4 TEC 06 can also be used as an electronic load to verify the battery or power output capacity Parameter 1 Max Current 3 5A error 0 5 2 Max Power 16W 3 Operating Temperature 20 70 Celsius Features 1 Can connect computer and draw discharge curve 2 Encoder switch shuttle operation easy and convenient 3 Precise current the full range error is within 0 5 4 Integrated fan discharge power can be up to 16W and the fan will be auto on off according to the power 5 Support 4 wire measurement and it can measurement battery internal 6 Max connection voltage 15V and power off voltage can be adjusted randomly in the range of 1 0 12V step length 0 05V 7 When the battery current is not enough the detector will automatically adjust set current until the actual current meets the set value when the actual current is lower than 40 set value the detector will end up discharging 8 MINI USB interface 5V voltage power supply and the actual current consumption is within 240mA 9 Max detection capacity is 50000
