TB6560 Stepper Motor Driver Board 3A CNC Router Single Axis DC 12V 24V

Features Definitely use the new chips imported from Japan TB6560 With large heat sink to ensure good heat dissipation Input signal high speed optocoupler isolation guarantee not losing steps Semi flow mode adjustable semi flow current adjustable not the general design on the market with a variety of semi flow model and semi flow current setting function Attenuation model adjusted for all the motors can be locked when no noise Ultra small the overall size 62mm 75mm installation of four mechanical positioning hole size 65mm 55 hole size 3mm The form of stud type connectors and an optional plug in Specifications Rated voltage DC 12V 24VMaximum current 3 5ACurrent adjustable Current Settings 0 5A 1A 1 5A 1 8A 2A 2 5A 3ASubdivision adjustable Excitation Mode 1 2 8 16Attenuation adjustable Decay Mode 0 no decay mode 25 of the slow decay mode 50 of the normal mode100 Fast Decay mode Decay mode of regulation by different motors to match impedance thereby eliminating the noise when locked stepper motor and motor movement in the shake Automatic half current setting Torque Settings No pulse when the current 20 to normal operating current of 20 50 no pulse current 50 to normal operating current75 no pulse current 75 to normal operating current100 no pulse when the current 100 to normal operating currentPackage Included 1 x 3A CNC Router Single Axis TB6560 Stepper Stepping Motor Driver Controller Board
