TAS5630 High Power Digital Power Amplifier Board Deluxe Edition 300W+300W Home Digital Power Amplifier Board

Description OPA1632 is a fully differential amplifier used to drive high performance audio analog to digital conversions ADCs The highest audio quality it provides very low noise and output driver this application is optimized for the characteristics of OPA1632 Excellent gain bandwidth of 180MHz 50V μs and very fast slew rate resulting in very low distortion of 0 000022 Very low input noise of 1 3nV √Hz further ensures the maximum signal to noise ratio and dynamic range Fully differential The flexibility of the structure makes it easy to achieve single ended fully differential output conversion The differential output reduces even harmonics and reduces common mode noise interference OPA1632 provides ADCs with excellent performance and high performance audio PCM1804 The driver such as the shutdown function during use is also enhanced To increase the flexibility of the amplifier TI s TAS5630 is a 300W stereo total power 600W class D amplifier with integrated feedback analog input which can provide up to 300W stereo from a single power supply of 50V to a 4 ohm speaker with a traditional class AB amplifier Performance 0 03 THD and power efficiency of a Class D amplifier Its SNR is greater than 100dB PSRR is 80dB and the power stage efficiency is as high as 88 Features 1 Use original TAS5630 OPA1632DR2 The main filter electrolytic capacitor adopts a capacity of 470UF 100V 43 The resistance uses five ring metal resistors and the main circuit uses fi
