T50N USB Dual Channel Power Monitor PD QC3.0 QC2.0 Tester Meter Voltage Current Capacity Table Stainless Steel Case

Features: Voltage, current, power measurement, Ah, Wh capacity, energy display Load resistance measurement shows the equivalent resistance, QC, FCP, PD monitoring (non-decoy) Dual voltage and current real-time curve Specifications: Model T50N dual USB table Display 2.6 inch IPS TFT 320 * 240 Dimensions 95 * 50 * 14mm Sampling resistance 25 milliohms Own internal resistance 50 milliohms Power consumption about 0.6W (120mA at 5V) Fast charge trick Do not support D + D-voltage not displayed Voltage range 3-25V (independent power supply 0-25V) Current range 0-5A Resolution 0.001V 0.001A Accuracy 0.03V 0.005A Input Interface USB-A male * 1 Micro USB * 2 Type-C * 2 Output Interface USB-A * 2 Type-C * 2 Power Interface Micro USB Female * 1 Note: 1. The bold line represents the power line, take a large current, if 5A circuit, to ensure that thick line part of the circuit and the pad can withstand 5A current for a long time; 2. Two ways common ground; Power can also be replaced by a road, with 2 loads; 3. 5V power supply available OUR supporting stepping plate steal electricity from 1, 3-25V can work; 4. Because the power supply 5V is connected 1117 change 3.3V, and 5V direct access to the OP07 and these two devices in the following 10V can work properly, 5V then slightly higher point, such as (6V) but be sure Stable, or OP07 at different voltage offset is not the same, leading to the need to recalibrate; 5. Since this product is based on Usart-GPU production, all interfaces are fully customizable with the host GpuMaker to suit the product: Package includes: 1 x T50N Dual USB Power Monitor
