Supstronics X200 Multifunction Expansion Board For Raspberry Pi B+

Supstronics X200 Multifunction Expansion Board For Raspberry Pi B Description The expansion board is directly connected on top of the Raspberry Pi using the board GPIO header pins and no wiring nor soldering is required and duplicated the 40 pin header of the R Pi in order to support existing expansion boards X200 is only fully compatible with Raspberry Pi Model B The company emphasizes that their HDMI to VGA converter is not powered by the R Pi HDMI port as this is known to cause issues You can find more information including instructions to build the RTC drivers and control the servo with WiringPi on the companys Raspberry Pi page Feature Input Voltage6V to 21Vdc converted to 5V 3A via step down DC DC converter to power the Raspberry Pi VGA outputHDMI to VGA converter supporting up to UXGA 16001200 and 1080p with 10 bit DACAudio3 5mm MIC in jack 3 5mm stereo audio jack SPDIF output audio IO connector Microphone input and stereo audio amplifier 3 3Wx2 Wireless WiFi IEEE 802 11b g n with antenna IR sensor 38KHz USBself powered USB hub with 3 portsRTCBased on DS3231SN with included CR2032 batteryServo support8 channel Darlington driver chip ULN2803 allowing to control electronic circuits which require more current I OsPower output connector headers to access camera connector on top of the Raspberry PiMiscDIP switch to remove connection from RPis pin headerDimensions85 x 56mm Same size as Raspberry Pi Read more http www suptronics
