Speed Reduction Motors Part Self Locking Gear Motor 6x50mm Shaft Wear Resistant Carbon Brush Low Noise For DIY DC6V 150RPM

Speed Reduction Motors Part Self Locking Gear Motor 6x50mm Shaft Wear Resistant Carbon Brush Low Noise for DIY DC6V 150RPM Specification: Item Type: Gear Motor Material: Zinc Alloy + Copper + Carbon + Stainless Steel Function: Industrial drive device. Output Shaft Size Diameter x Length: Approx. 6 x 50mm / 0.2 x 2in Shaft Type: M6 Threaded Shaft Speed: speed. Rotation: CW rotation and CCW rotation. DC 6V Gear Motor Specification: Gear Ratio Ratio 40 65 90 150 200 260 340 600 1000 No Load Current MA Less than or equal to 100 Less than or equal to 100 Less than or equal to 100 Less than or equal to 100 Less than or equal to 100 Less than or equal to 100 Less than or equal to 100 Less than or equal to 100 Less than or equal to 100 No Load Speed rpm 150 90 66 40 30 23 18 10 6 Rated Torsion kg.cm 0.2 0.5 0.7 2 5.3 6.7 9 15.9 26.5 Rated Rotate Speed rpm 120 70 51 30 22 18 15 7.5 4 Rated Current A Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Maximum Torsion Kg.cm 0.9 1.6 2 7.5 10 13 18 30 45 Stalled Current A 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 3.3 DC 12V Gear Motor Specification: Gear Ratio Ratio 40 65 90 150 200 260 340 600 1000 No Load Current MA Less than or equal to 60 Less than or equal to 60 Less than or equal to 60 Less than or equal to 60 Less than or equal to 60 Less than or equal to 60 Less than or equal to 60 Less than or equal to 60 Less than or equal to 60 No Load Speed rpm 150 90 66 40 30 23 18 10 6 Rated Torsion kg.cm 0.2 0.5 0.7 2 5.3 6.7 9 15.9 26.5 Rated Rotate Speed rpm 120 70 51 30 22 18 15 7.5 4 Rated Current A Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Less than or equal to 0.6 Maximum Torsion Kg.cm 0.9 1.6 2 7.5 10 13 18 30 45 Stalled Current A 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 1.7 Package List: 1 x Gear Motor Note: 1. Do not place the product in an environment that is too corrosive humid or in high temperature; 2. Please supply power according to the use voltage using other voltages may cause fire and product damage.
