SmallRig Handheld Kit for BMPCC 6K Pro Camera
The SmallRig Handheld Kit 3584 is made of aluminum alloy, sturdy and durable, with multiple 1/4"-20 threaded holes to support other accessories. The kit comes with a universal Top Handle 1446 and a NATO Side Handle HSN2427 for quick switching between two handheld shooting modes, hence stable movement shooting solutions.
The built-in T5 SSD & USB-C Cable Clamp is further locked via a knob to prevent accidental disconnection and the baseplate with dual 15mm rod fits accessories such as Lens Support BSL2644, Follow Focus 3010, Matte Box 2660, etc., for handheld & tripod shooting.
Note: Please use a spanner to refix the screw for safety.
- Camera Cage -
SmallRig Full Cage for BMPCC 6K Pro 3270 is specially designed for BMPCC 6K Pro. It secures the camera via a 1/4''-20 screw on the top and two on the bottom to prevent wiggles and comes with rubber pads at the bottom to prevent scratching. Its top features an Arri locating hole, a 1/4''-20 threaded hole, and a cold shoe for attaching Arri Locating Handle 2165 and Samsung T5 SSD Mount 3272. The cage also provides slots for neck-straps. Its left side is equipped with a NATO rail and a 1/4''-20 threaded hole for mounting NATO Handle 2270 and HDMI&USB-C Cable Clamp 3271; its right top and left bottom holes can support focus motor rod mount.
The built-in Samsung T5 SSD Mount takes up very little space and improves compactness and suits SSD&USB-C cable clamp to ensure stability and smooth data transmission while shooting. This cage incorporates multiple threaded holes on the bottom to attach Quick Release Plates 1280 & 2146 and DJI RS2 stabilizer and a built-in spanner for easy disassembly. Overall, the cage fits the body perfectly without blocking its holes, slots, vents, or battery door, hence a comfortable grip experience.
Features• Form-fitting cage for BMPCC 6K Pro; disassembled to become a half cage
• Supports SSD mount, HDMI&USB-C cable clamp, and focus motor rod mount
• Built-in Samsung T5 SSD Mount on the bottom takes up very little space and improves compactness
• Fitted body lines for a comfortable grip
- T5 SSD Cable Clamp -
SmallRig T5 SSD Cable Clamp for BMPCC 6K Pro 3300 can be fixed via one thumb screw to protect SSD USB-C cable and prevent disconnection during shooting. The clamp is compact, space-saving and easy to carry around.
Features
• Compact and easy to carry around
• Prevents T5 SSD and USB-C cable from disconnection and ensures stable transmission during filming
• Fixed via a thumb screw, allowing quick assembly and disassembly
- HDMI & USB-C Cable Clamp -
SmallRig HDMI&USB-C Cable Clamp for BMPCC 6K PRO 3271 works only with the new cage 3270. It locks onto the left side of the cage via two thumbscrews to secure HDMI and USB-C cables and prevent signal interruptions during filming. Besides, it comes with a hex spanner to help ensure secondary fixation.
Features
• Designed to work with SmallRig Full Cage for BMPCC 6K PRO 3270
• Secures and protects HDMI and USB-C clamp
• Easy-to-grip 1/4"-20 thumb screws for quick assembly and disassembly
Note: Please use a spanner to refix the screw for safety.
- Top Handle -
SmallRig Top Handle 1446 could be mounted to the top plate of cage via two 1/4'' screws. It could provide lots of convenience when utilized in handheld shooting. The good-quality rubber handle is very good looking and the special design increases its friction during handheld shooting. It is equipped with a cold shoe on the top for attaching microphone and other accessories.
- Universal LWS Baseplate with Dual 15mm Rod Clamp -
Lightweight and compact, SmallRig Universal LWS Baseplate with Dual 15mm Rod Clamp 3357 fits mainstream DSLR and mirrorless camera cages on the market. It works with dual 15mm rods to attach such accessories as lens support, follow focus, and matte box during handheld shooting and tripod shooting. It can ensure 85mm optical height when used with BMPCC 6K Pro Cage 3270. Its specially-designed bottom enables you to replace Samsung T5 SSD without removing the baseplate. Large built-in rubber pads prevent scratching and twisting. Multiple threaded holes at the bottom allow attachment of various sizes of quick release plates for tripod shooting.
Features
• Light and compact, weighing only 150g
• Compatible with mainstream DSLR and mirrorless camera cages on the market
• Suits BMPCC 6K Pro cage to ensure 85mm optical height and allow replacing Samsung T5 SSD without removing the baseplate
• Multiple built-in threaded holes at the bottom, enable attachment of various sizes of quick release plates
- NATO Side Handle -SmallRig Aluminum NATO Side Handle HSN2427 is designed to provide a comfortable handheld shooting for cameramen. A built-in hex on the bottom can be used to adjust the handle up and down based on your needs. If you want to use the handle on the other side of the cage, use the hex to take off the connection metal part of handle and change the direction.
It is locked via NATO clamp to make your setup quick release and fits any cage featuring NATO rail on side. It comes with one cold shoe and three 1/4"-20 thread holes allow for mounting accessories. It weighs 237g only and features an aluminum body with anti-slip silicone gel coverings to provide a comfortable and lightweight handheld shooting. Also this handle can be used with a hand strap for more security.
Features
• Fits any cage featuring NATO Rail on each side
• Built-in Allen wrench allows to change the direction of the handle and adjust the height
• Mounting holes & cold shoe on top of the handle for accessory attachment
• Aluminum body with anti-slip silicone gel coverings provide a comfortable and lightweight handheld shooting
