Sipeed MAIX Dock M1 M1W K210 AI+lOT Deep Learning Vision 2.4 Inch LCD + OV2640 Camera Development Board Kit

Main Features: CPU: RISC-v 64bit dual-core processor, 400Mhz standard frequency (overclocked) Image recognition: qvg@60fps/vg@30fps MEMS microphone :MSM261S4030H0 Sensitivity :-26(dB, dbfs@1khz 1 Pa) Audio DAC+PA(support 2x3w speaker) Micro SD card slot (TF card) Download circuit: simply connect USB type-C cable to complete the download 24P DVP and 24P MCU LCD connector Wireless function (optional): 2.4g 802.11.b/ G /n Functions overview: 1. Main modules: Sipeed M1 or M1WAIOT modules (for more details, please read the following specifications: Sipeed M1 specification v1.1.pdf and Sipeed M1w specification V1.0) 2. GPIO interface: all GPIO are connected to 2.54mm spaced direct insert pads 3. Micro SD card (TF card) slot: slot for small size TF card 4. Onboard MEMS microphone: MSM261S4030H0 is an omnidirectional, bottom-port, 12S digital output MEMS microphone. It has high performance and reliability, 24P 0.5mm EPC connector 5. DVP camera interface :24P 0.5mm FPC connector (8 bit MCU LCD) 6. Audio: TM8211 DAC + PAM8403 PA(support 2x3W speaker) 7. LCD interface: Boot button and Reset button 8. Size: 52.33mm x 37.34mm Package includes: 1 x M1w+2.4 inch screen + ov2640 (optional) 1 x M1+2.4 inch screen + ov2640 (optional)
