Signal Frequency Generator OLED Display Phase-Locked Loop Module Sensors Excitation Source Line Loss Attenuation Detection Module

Features:
The MAX2870-OLED is used in conjunction with an external loop filter and external reference frequency to implement an integer N frequency-locked loop (PLL) frequency synthesizer.
Phase-locked loop module with OLED display, USB communication port for upper computer, integrated button operation, wide voltage power supply, nice human-machine interaction interface, etc.
The MAX2870 features an integrated voltage-controlled oscillator (VCO) with a basic output frequency ranges of 3000 MHz to 6000 MHz.
In addition, a 1/2/4/8/16/32/64 crossover circuit allows users to generate radios frequency output frequencies down to 23.5 MHz.
For applications requiring isolation, the radios frequency output stage can be muted. The mute function can be controlled via pins or software.
An auxiliary radios frequency output is also available and can be switched off when not in use.
Multifunction design, it has point frequency, frequency sweeping, frequency hopping and other basic functions.
Module applications: radios frequency signal frequency generator, sensors excitation source, line loss attenuation detection, scanning clock signal generator.
